Beschreibung
PINNACLE OF PERFORMANCE.
Mit unserer ST4K-Reihe, die mit der PURE Drive™-Technologie ausgestattet ist, um den vollen Nutzen aus der Eingangsleistung zu ziehen (97 % gehen direkt an die LEDs), und der aggressiven Bauqualität ist die ST4K für den Test gebaut.
JACK OF ALL TRADES.
Der ST4K 28-Zoll-LED-Lichtbalken vereint die Stärken der Spot- und Flood-Reflektorverteilung, um eine erstaunliche Reichweite von 755 m zu erzielen, mit 55 m auf jeder Seite des Fahrzeugs mit dem Flood-Strahl.
AN ENVIABLE PEDIGREE.
Die STEDI ST4K basiert auf dem STEDI TYPE X Stammbaum, dem Musterbeispiel für leistungsstarke Fahrlichter. Mit der Kraft von 40 x OSRAM's® OSLON® LED wird die ST4K 28 Zoll LED Light Bar zum perfekten Allrounder für jede Situation;
The nitty
gritty.
PERFORMANCE THAT LETS YOU TURN THE SUN BACK ON
- STEDI ST4K-52 features 52 of OSRAM’s® finest OSLON® LED, selected for its high luminous flux and perfectly match optical properties.
- 8 Flood + 36 Spot + 8 Flood reflector distribution forms a remarkable beam that pushes the wide beam out at 50° and spot beam at 5.8° all the way to staggering 1 lux @ 755m
- Crystal White 5700K Colour temperature offers stunning clarity and definition with excellent Colour Rendering Index (CRI).
- Our Pure-Drive™ circuit design allow 97% of input power to go directly to LEDs.
BUILT TO GO ALL NIGHT
- A360.0 Cast face plate, extruded Aluminum heat sink | finished in 100% Polyester UV and abrasion resistant powder coat, ensures that our bars will never discolour.
- Pressure Equalization vent with Gore® membrane | Protects against water ingress, dust & contaminants.
- IP68 | Dust & Particle tight + Water-proof up to 3 meters – Drown it, we insist!
- Environmentally sealed Deutsch ® DT connector.
Backed by our no nonsense 5-year replacement warranty.
MOUNT IT YOUR WAY
We know you want flexible mounting options, which is why we’ve included two seperate mounting options.
- The included adjustable sliding mounts allow you to align the mount bolts to any pre-existing mounting holes. Make mounting to UHF tabs or Bull bar dech very straight forward.
- Or use our 3mm thick 304 Stainless steel side brackets, which feature + or - 15mm height adjustment.
EASY-FIT Plug & Play High Beam Wiring Harness included.
Included is our acclaimed Easy-Fit Plug and Play Wiring Harness with supplied H4 and HB3 Adapters, making for an easy connection to high beam. Further unlike other brands our kit has built in electronics making our harness compatible with even the most modern and sophisticated wiring systems. Whether your vehicle is positive or negatively switched our harness will work right out of the box without any modification whatsover.
No nonsense 5 Year Replacement Warranty backed by an Australian company which has a bricks & mortar presence.
Tech Specs
| LED MANUFACTURER | OSRAM (Oslon)® |
| LED COUNT | 52 |
| VOLTAGE | 12V & 24V |
| LENS MATERIAL | OPTICAL GRADE, HARD COATED LEXAN |
| LUMENS | 12,480 LUMENS |
| PEAK INTENSITY (CANDELA) | 574,080cd |
| HOUSING MATERIAL | A360.0 Cast face plate, extruded Aluminum heat sink |
| AMPERES | 11.5A @ 13.6v |
| LIFESPAN | 50,000 |
| FLOOD BEAM | 50° |
| SPOT BEAM | 5.8° |
| INGRESS PROTECTION | IP68 |
| OPERATING TEMP | -40°C to 60°C |
| WEIGHT | 3.660kg |
